Indexes

Overview

Indexes is the searchable list page for table indexes in the warehouse area. Use it to find index definitions by schema, table, or index name, and then open an index for maintenance.

Function

The page combines a search filter with a read-only indexes grid. The search field narrows the list by index name, schema, or table.

The grid shows where each index belongs and whether it is clustered, unique, or marked as the primary key. Double-click an index row to open the selected index in the Index page. Use New to create an index, or Delete to remove the selected index after confirmation.

Access

Open the indexes list from the DWH toolbar or from the Indexes node in the navigation tree. When opened from a table context, the list can focus the index records related to that table.

How to access

Navigation tree

Indexes -> List indexes. From a table index, use Edit index.

Toolbar

DWH -> Indexes

Diagram

Not direct. Use the DWH toolbar or the Indexes navigation-tree node.

Visual element

Indexes list page

Screen overview

ID	Property	Description
1	Search criteria	Filter area at the top of the page.
2	Search field	Text field used to filter index records by index name, schema, or table.
3	Search	Runs the filter and refreshes the indexes grid.
4	Clear filter	Clears the search field and reloads the full indexes list.
5	Schema	Grid column that shows the schema for the indexed table.
6	Table	Grid column that shows the table connected to the index.
7	Index	Grid column that shows the index name.
8	Clustered	Grid column that shows whether the index is clustered.
9	Unique	Grid column that shows whether the index enforces unique values.
10	Primary key	Grid column that shows whether the index is the primary key for the table.
11	Indexes grid	Read-only result list. Double-click a row to open the selected index.
12	New	Opens the Index page for a new index.
13	Delete	Removes the selected index after confirmation.
